帕金斯柴油發動機專用維修工具Special tools
專用工具
List of special tools
特殊工具列表
These tools are available from your local Perkins
這些工具可從您的本地帕金斯
Distributor.
經銷商。
If you cannot obtain the correct tool locally contact
如果你無法獲得正確的工具本地接觸
Perkins Parts Limited, Frank Perkins Way, North
帕金斯有限公司，帕金斯的方式，北
Bank Industrial Park, Irlam, Manchester M44 5PP.
銀行產業園，曼徹斯特公墓，5pp M44。
Some additional special tools may be necessary for
一些額外的特殊工具可能是必要的
use with the fuel injection pump and the starter motor.
使用與燃油噴射泵和起動電機。
A list of these is given in the relevant section.
在有關部分中列出了這些列表。

Number

Description

Illustration

21825 739

Valve spring compressor

21825 740

Adaptor

(Use with 21825 739)

21825 741

Stirrup

(Use with 21825 739)

21825 755

Stirrup

(Use with 21825 739)

21825 756

Reamer for exhaust valve guides

21825 765

Reamer for inlet valve guides

242

26

Number

Description

Illustration

21825 767

Face cutter

(Use with 21825 765)

21825 768

Reamer

(Use with 21825 765)

21825 771

Removal tool for fuel injector sleeves

21825 773

Tap

21825 776

Expander tool for fuel injector sleeves

21825 782

Height gauge

243

Perkins  Engines Company Limited

26

Number

Description

Illustration

21825 786

Dial gauge and holder

21825 787

Check plate for cylinder liners

(Use with 21825 786)

21825 790

Remover tool for cylinder liners

21825 793

Ring expander

21825 809

Guide studs

21825 810

Remover/replacer

244

26

Number

Description

Illustration

21825 811

Guide studs

21825 822

Lift adaptor for engine

21825 825

Strap Wrench

21825 841

Valve seat tool

21825 842

Valve seat cutter

21825 843

Guide pin for c onnecting rods

245

Perkins  Engines Company Limited

26

Number

Description

Illustration

21825 844

Retainers

21825 845

Piston ring compressor

21825 846

Torque wrench 8 to 54 Nm (6 to 40 lbf ft)

21825 849

Slide hammer

21825 854

Adaptor

(Use with 21825 849)

21825 855

Remover tool for cup plugs

(Use with 21825 849)

246

26

Number

Description

Illustration

21825 858

Crankshaft bearing remover

(Use with 21825 849)

21825 859

Remover/replacer

(Use with 21825 849)

21825 860

Adaptor

(Use with 21825 849)

21825 861

Drive handle

21825 866

Replacer kit for cup plugs

(Use with 21825 861)

21825 867

Insert tool for valve seats

(Use with 21825 861)

247

Perkins  Engines Company Limited

26

Number

Description

Illustration

21825 876

Lift bracket for fuel injection pump

21825 881

Special torque wrench

(Use with 21825 882)

21825 882

Adaptor for torque wrench

(Use with 21825 881)

21825 883

Ball type expander tool

21825 885

Remover for inlet valve guides

21825 886

Remover for exhaust valve guides

248

26

Number

Description

Illustration

21825 887

Replacer for inlet valve guides

21825 888

Replacer for exhaust valve guides

21825 889

Extractor for valve bridge guides

21825 890

Depth tool for valve bridge guides

21825 892

Holder

21825 893

Cutter for valve seat removal

(Use with 21825 892)

249

Perkins  Engines Company Limited

26

Number

Description

Illustration

21825 894

Rolling tool

(Use with 21825 892)

21825 895

Lift adaptor for cylinder head

21825 896

Removal tool for valve seat inserts

21825 902

Lapping tool

21825 905

Remover/replacer

21825 906

Lift adaptor for flywheel

250

26

Number

Description

Illustration

21825 915

Service kit for fuel injecto sleeves

21825 991

Torque wrench 30 to 150 Nm (20 to 110 lbf ft)

21825 992

Torque wrench 70 to 310 Nm (50 to 230 lbf ft)

27610005

Remover/replacer

27610008

Alignment tool

VP 5908

Build stand - engine

(Use with mounting brackets:

VP 5941 and VP

251

Perkins  Engines Company Limited
