SECTION 01—General Information

Group 000—Safety

Group 001—Engine Identification and Application

Charts

Group 002—Fuels, Lubricants and Coolants

02

SECTION 02—Repair and Adjustments

Group 010—Engine Rebuild

Group 020—Cylinder Head and Valves (Two-Valve

Head Engines)

Group 021—Cylinder Head and Valves (Four-Valve

Head Engines)

Group 030—Cylinder Block, Liners, Pistons and

Rods

Group 040—Crankshaft, Main Bearings and

Flywheel

03

Group 050—Camshaft, Balancer Shafts and Timing

Gear Train

Group 060—Lubrication System

Group 070—Cooling System

Group 080—Air Intake and Exhaust System

Group 090—Fuel System

Group 100—Starting and Charging Systems

SECTION 03—Theory of Operation

Group 120—Base Engine Operation

04

SECTION 04—Diagnostics

Group 150—Observable Diagnostics and Tests

SECTION 05—Tools and Other Materials

Group 170—Repair Tools and Other Materials

Group 180—Diagnostic Service Tools

Group 190—Dealer Fabricated Service Tools

SECTION 06—Specifications

Group 200—Repair and General OEM

Specifications

05

Group 210—Diagnostic Specifications

Group 000—Safety . . . . . . . . . . . . . . . . . . . .01-000-1

Group 001—Engine Identification and Application

Charts

Engine Model Designation. . . . . . . . . . . . . . . .01-001-1

Engine Serial Number Plate Information . . . . .01-001-3

OEM Engine Option Code Label . . . . . . . . . . .01-001-4

Information Relative to Emissions

Regulations . . . . . . . . . . . . . . . . . . . . . . . . .01-001-5

Engine Application Charts . . . . . . . . . . . . . . . .01-001-6

Group 002—Fuels, Lubricants and Coolants

Diesel Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . .01-002-1

Bio-Diesel Fuel . . . . . . . . . . . . . . . . . . . . . . . .01-002-2

Lubricity of Diesel Fuel . . . . . . . . . . . . . . . . . .01-002-3

Dieselscan Fuel Analysis. . . . . . . . . . . . . . . . .01-002-3

Diesel Engine Break-In Oil . . . . . . . . . . . . . . .01-002-4

Diesel Engine Oil—Non-Certified and Tier I

Certified Engines . . . . . . . . . . . . . . . . . . . . .01-002-5

Diesel Engine Oil—Tier II Engines . . . . . . . . .01-002-6

OILSCANâ, OILSCAN Plusâ,

COOLSCANä and COOLSCAN PLUSä . . .01-002-7

Grease . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .01-002-8

Diesel Engine Coolant. . . . . . . . . . . . . . . . . . .01-002-9

Diesel Engine Coolants, Supplemental

Additive Information . . . . . . . . . . . . . . . . . .01-002-10

Testing Diesel Engine Coolant . . . . . . . . . . .01-002-11

Supplemental Coolant Additives . . . . . . . . . .01-002-12

Operating in Warm Temperature Climates . .01-002-12

Flush and Service Cooling System . . . . . . . .01-002-13

Disposing of Coolant . . . . . . . . . . . . . . . . . . .01-002-14

4045TF275 柴油發動機

4 ............................. Number of cylinders

4.5 .......................... Liter displacement

T ............................ Aspiration code

F ............................ User code

275 ......................... POWERTECHâ application codeAspiration Code

D ............................ Naturally aspirated

T ............................ Turbocharged, no aftercooling

A ............................ Turbocharged and air-to-coolant aftercooled

H ............................ Turbocharged and air-to-air aftercooledUser Factory Code

AT .......................... Agritalia srl (Vittoria, Sicily, Italy)

CQ ......................... John Deere Brazil (Horizontina, Brazil)

DW ......................... John Deere Davenport Works (Davenport,Iowa)

E ............................ John Deere Ottumwa Works (Ottumwa, Iowa)

F ............................ OEM (Outside Equipment Manufacturers)

FF .......................... Deere-Hitachi (Kernersville, North Carolina)

FG .......................... Goldoni S.P.A. (Modena, Italy)

FM ......................... Marine Engines

H ............................ John Deere Harvester Works (East Moline,Illinois)

KV .......................... John Deere Commercial Worksite Products(Knoxville, Tennessee/Dubuque, Iowa)

L ............................. John Deere Werke Mannheim (Germany)

LA .......................... John Deere Werke Mannheim (Germany)(Engines with Bosch VP44 Injection Pump)

LV .......................... John Deere Commercial Products (Augusta,Georgia)

N ............................ John Deere Des Moines Works (Des Moines,Iowa)

P ............................ Industrias John Deere Mexico S.A. de C.V.(Saltillo/Monterrey, Mexico)

PY .......................... Larson & Toubro Ltd. (Pune, India)

RW ......................... John Deere Waterloo Tractor Works (Waterloo,Iowa)

T ............................ John Deere Dubuque Works (Dubuque, Iowa)

T8 .......................... Cameco Industries (Thibodaux, Louisiana)

TJ ........................... Timberjack (Deere) (Sweden/Finland/Canada)

YC .......................... John Deere Jialian Harvester Co. Limited(China)

Z ............................ John Deere WERKE Zweibrucken (Germany)Application Code

001, etc. ................. See Engine Application Charts, later in thisGroup

4045TF275 柴油發動機修理和調整

John Deere約翰迪爾強鹿4045TF275 柴油發動機修理和調整
